Teledyne LeCroy PETrainer Scripting Language
16
Example 2:
This example shows how to send a Completion with Data TLP. This Completion TLP returns
Successful Completion (SC) status.
Requester is Function 0 of Device 0 on Bus 0.
Completer is Function 0 of Device 1 on Bus 0.
This completes the TLP request with Tag Number 4.
This is the last Completion of the Split Transaction, since ByteCount field is equal to the number of bytes
transferred and BCM is not set.
Packet = TLP {
TLPType = CplD
RequesterId = (0:0:0)
CompleterId = (0:1:0)
Tag=4
ComplStatus = SC
ByteCount = 32
Payload = ( 0x00000001, 0x00000002, 0x00000003, 0x00000004,
0x00000005, 0x00000006, 0x00000007, 0x00000008 )
}
