Teledyne LeCroy PETrainer Scripting Language
25
3.3.1 SetType = TS1, TS2
Parameter
Values Default Comment
LinkNumber 0:255, PAD PAD Link Number within component
LaneNumber 0:31, PAD PAD Lane Number within Port
N_FTS 0:255 0 The number of fast training ordered sets
required by the Receiver to obtain reliable
bit and symbol lock.
TrainingControl (X,X,X,X) (0,0,0,0) Training control bits.
The order of the bits is as follows:
(HotReset, DisableLink, Loopback,
DisableScrambling)
Identifier (X,X,X…) D10.2 for TS1 and
D5.2 for TS2 Use the same format as in Packet = Raw
(see page 29), with exception of 10-bit
codes.
In x4, x8 or x16 configurations, the keys listed above apply to all lanes.
When you want to specify parameters for a particular lane, use the following format:
@ =
