PETracer Software User Manual

Chapter 4: Reading CATC Traces

Teledyne LeCroy

25

4.7 Show Header Fields

You can view details about header fields by opening the Show Header Fields
dialog box.

Step 1 Click a header. A pop-up menu appears.

Step 2 Select Show Header Fields. The following dialog box opens.

Step 3 Use the Prev and Next buttons to navigate to other headers.

Set Start Quick Timing Marker

Sets the start packet for the Quick Timing marker. An S symbol is displayed at
the packet.
