8.10 Packet Header Bar
The Packet Header bar shows packet header information.
To obtain the Packet Header bar, select Report > Packet Header
or click the
Packet Header toolbar icon.
The toolbar allows you to
Save, go to Previous or Next, display Hexadecimal or Binary, and show
the Packet Data window.
8.11 Packet Data Window
The Packet Data window shows packet information.
To obtain the Packet Data window, select Report > Packet Data
or click the
toolbar icon.
