Teledyne LeCroy PCIe 2.0 Mid-Bus Probe Installation Guide Version 2.4
26
8 Ordering Information
Use the following table of part numbers and descriptions to order components of the
mid-bus probes.
Summit T2-16 Analyzer Mid-Bus Probes (PCIe 2.0)
PE017ACA-X
Summit T2-16 Gen2 x8 Mid-Bus Probe Kit (includes Mid-Bus Pod, iPass Y-cable,
Ref Clock Cable, full-size retention module) [Two pods required for bi-directional x16]
PE018ACA-X
Summit T2-16 Gen2 x4 Mid-Bus Probe Kit (includes Mid-Bus Pod, iPass Y-cable,
Ref Clock Cable, half-size retention module)
PE035UIA-X Mid-Bus Pod, Summit T2-16 (x8 pod for Mid-Bus probing)
PE010UCA-X IPass Y-Cable, Summit T2-16, 1 meter
PE008ACA-X Mid-Bus Probe Cable, x8 full-size probe header cable (connects to Mid-Bus box)
PE009ACA-X Mid-Bus Probe Cable, x4 half-size probe header cable (connects to Mid-Bus box)
PE012UCA-X
VHDI-to-iPass Cable, x8, Summit T2-16, 1 meter (For use with Gen1 legacy interposers
and probes)
PE014UCA-X Reference Clock Cable (to connect from DUT to Mid-bus Pod)
PE009UCA-X Daisy Chain Cable (to connect between two Mid-bus Pods in x16 applications)
PETracer Mid-Bus Probes (PCIe 1.0)
PE001ACA-X
PETracer Mid-Bus Probe (supports Gen1 x8 Lane Widths; includes Mid-Bus Probe Pod,
Header Cable, Full Size Retention Module)
PE004ACA-X
PETracer Mid-Bus Probe (supports Gen1 x4 Lane Widths; includes Mid-Bus Probe Pod,
Header Cable, Half Size Retention Module)
PE005ACA-X
PETracer Mid-Bus Probe (supports Gen1 x8 Lane Widths; includes Mid-Bus Probe Pod,
Header Cable, Multi-lead cable probe)
PE001UAA-X PETracer Mid-Bus Probe Pod Gen1
PE005UIA-X
Mid-Bus Probe Test Interposer (includes x8 Interposer Card, Mid-Bus Probe footprint
and retention module)
180-0068-00 PETracer ML x1/x4 Cable Assembly, 1 meter
180-0066-00 PETracer x8 Cable Assembly, 1 meter
PE003ADA-X PETracer EML x1-x8 Y-Cable
PE002ACA-X Mid-Bus Probe Header Cable (Full Size)
PE003ACA-X Mid-Bus Probe Header Cable (Half Size)
Accessories
232-0004-00 Retention Module Half Size (Gen1 or Gen2)
232-0003-00 Retention Module Full Size (Gen1 or Gen2)
