Teledyne LeCroy PCIe 2.0 Mid-Bus Probe Installation Guide Version 2.4
13
x16 (in Two Bi-directional Footprints) Mid-Bus Probe Pinout
on two Full-size Headers (Summit only)
Pin Signal Name Pin Signal Name
G1 GND (Gen2 only)
A2 GND A1 C0p- Upstream
A4 C0p- Downstream A3 C0n- Upstream
A6 C0n- Downstream A5 GND
A8 GND A7 C1p- Upstream
A10 C1p- Downstream A9 C1n- Upstream
A12 C1n- Downstream A11 GND
A14 GND A13 C2p- Upstream
A16 C2p- Downstream A15 C2n- Upstream
A18 C2n- Downstream A17 GND
A20 GND A19 C3p- Upstream
A22 C3p- Downstream A21 C3n- Upstream
A24 C3n- Downstream A23 GND
A26 GND A25 C4p- Upstream
A28 C4p- Downstream A27 C4n- Upstream
A30 C4n- Downstream A29 GND
A32 GND A31 C5p- Upstream
A34 C15p- Downstream A33 C5n- Upstream
A36 C5n- Downstream A35 GND
A38 GND A37 C6p- Upstream
A40 C6p- Downstream A39 C6n- Upstream
A42 C6n- Downstream A41 GND
A44 GND A43 C7p- Upstream
A46 C7p- Downstream A45 C7n- Upstream
A48 C7n- Downstream A47 GND
G2 GND (Gen2 only)
Pin Signal Name Pin Signal Name
G1 GND (Gen2 only)
B2 GND B1 C8p- Upstream
B4 C8p- Downstream B3 C8n- Upstream
B6 C8n- Downstream B5 GND
B8 GND B7 C9p- Upstream
B10 C9p- Downstream B9 C9n- Upstream
B12 C9n- Downstream B11 GND
B14 GND B13 C10p- Upstream
B16 C10p- Downstream B15 C10n- Upstream
B18 C10n- Downstream B17 GND
B20 GND B19 C11p- Upstream
B22 C11p- Downstream B21 C11n- Upstream
B24 C11n- Downstream B23 GND
B26 GND B25 C12p- Upstream
B28 C12p- Downstream B27 C12n- Upstream
B30 C12n- Downstream B29 GND
B32 GND B31 C13p- Upstream
B34 C13p- Downstream B33 C13n- Upstream
B36 C13n- Downstream B35 GND
B38 GND B37 C14p- Upstream
B40 C14p- Downstream B39 C14n- Upstream
B42 C14n- Downstream B41 GND
B44 GND B43 C15p- Upstream
B46 C15p- Downstream B45 C15n- Upstream
B48 C15n- Downstream B47 GND
G2 GND (Gen2 only)
