OPERATION AND SERVICE PROCEDURES
For the Electronic Range Control (ERC) (Models w/Two Piece Control)
45 RC231002 Rev. 3
Figure 41 - Bake/Timed Bake Circuit
Bake burner is cycled by RR1 (K2) relay which is controlled
by varying temperature sensor resistance.
Figure 42 - Clean Cycle - Phase I
Broil burner operates first 30 minutes of clean cycle.
Figure 43 - Lo/Hi Broil Circuit
Broil burner is cycled by RR2 (K3) relay which is controlled
by varying temperature sensor resistance.
Figure 44 - Clean Cycle - Phase II
Bake burner operates thirty (30) minutes into clean cycle.
Burner is cycled by RR1 (K2) relay which is controlled by
varying temperature sensor resistance.
TO AVOID THE RISK OF ELECTRICAL SHOCK, PERSONAL INJURY OR DEATH DISCONNECT POWER
BEFORE SERVICING, UNLESS TESTING REQUIRES IT.
