4.
Appendix
36
Ɣ I/O Parameter
No. Parameter name
Default
(reference)
Input
Range
Unit Remarks
149
IAI Protocol B/TCP connected
destination
IP Address (MANU Mode)(H)
192 0 to 255 - * Prohibited to set to 0 and 127
150
IAI Protocol B/TCP connected
destination
IP Address (MANU Mode) (MH)
168 0 to 255 -
151
IAI Protocol B/TCP connected
destination
IP Address (MANU Mode) (ML)
0 0 to 255 -
152
IAI Protocol B/TCP connected
destination
IP Address (MANU Mode) (L)
100 0 to 254 - * Prohibited to set to 0 and 255
153
IAI Protocol B/TCP connected
destination
Port No. (MANU Mode)
64611 0 to 65535 -
* Setting of 0 available when server
0 = connected port number not to be subject
(Only IP address is checked)
* Setting of 0 not available when client
154
IAI Protocol B/TCP connected
destination
IP Address (AUTO Mode)(H)
192 0 to 255 - * Prohibited to set to 0 and 127
155
IAI Protocol B/TCP connected
destination
IP Address (AUTO Mode) (MH)
168 0 to 255 -
156
IAI Protocol B/TCP connected
destination
IP Address (AUTO Mode) (ML)
0 0 to 255 -
157
IAI Protocol B/TCP connected
destination
IP Address (AUTO Mode) (L)
100 0 to 254 - * Prohibited to set to 0 and 255
158
IAI Protocol B/TCP connected
destination
Port No. (AUTO Mode)
64611 0 to 65535 -
* Setting of 0 available when server
0 = connected port number not to be subject
(Only IP address is checked)
* Setting of 0 not available when client
159 IAI Protocol B/TCP Self-Port No.
(AUTO Mode)
64516
1025 to
65535
-
* Caution: Set different numbers to each
self-port number. (Sharing of the
same number is allowed only in IAI
Protocol B/TCP self-port number
and MANU Mode/AUTO Mode.)
160
Vision System I/F connected
destination
IP Address (H)
192 0 to 255 - * Prohibited to set to 0 and 127
161
Vision System I/F connected
destination
IP Address (MH)
168 0 to 255 -
162
Vision System I/F connected
destination
IP Address (ML)
0 0 to 255 -
163
Vision System I/F connected
destination
IP Address (L)
102 0 to 254 - * Prohibited to set to 0 and 255
164
Vision System I/F connected
destination
Port No.
64613 0 to 65535 -
* Vision System I/F is dedicated for the
specifications of the client on IAI controller
side (Self-Port Number Automatic
Assignment)
* 0 Setting of 0 forbidden
