3. XSEL-R/S/RX/SX/RXD/SXD
16
[4] Default Gateway Setting
Set the default gateway to I/O Parameter No.140 to 143.
No. Parameter name
Default
(reference)
Input Range Unit Remarks
140 Network I/F Module 1
Default Gateway (H)
0 0 to 255 -
141 Network I/F Module 1
Default Gateway (MH)
0 0 to 255 -
142 Network I/F Module 1
Default Gateway (ML)
0 0 to 255 -
143 Network I/F Module 1
Default Gateway (L)
0 0 to 255 -
[5] Baud Rate Setting
Set the baud rate to I/O Parameter No.227.
It is recommended to set to Auto-negotiation for the baud rate setting.
No. Parameter name
Default
(reference)
Input Range Unit Remarks
227 Network I/F Module 1
Baud Rate
0 0 to 4 -
• At EtherNet/IP:
(0: Autonegotiation,
1: 10Mbps (Half-duplex),
2: 10Mbps (Full-duplex),
3: 100Mbps (Half-duplex),
4: 100Mbps (Full-duplex))
Set the baud rate to the value that matches with the baud rate (mode) of such as switching
hub.
Operation without matching the setting may lead to unstable communications. In case a value
out of the range of EtherNet/IP specifications is set, “D75: Fieldbus Parameter Error” is issued.
[6] I/O Port Assignment Classification Setting
Set the I/O port assignment Classification to I/O Parameter No.1.
No. Parameter name
Default
(reference)
Input Range Unit Remarks
1 I/O Port Allocation Type 1 0 to 1 -
0: Fixed Allocation
1: Automatic Allocation
• Reference 1 Priority of I/O Port Assignment
when automatically assigned
Port No.
(No.0 to 299/No.300 to 599)
1) Network I/F Module 1
2) I/O slot 1 (I/O1) Mounting board
3) I/O slot 2 (I/O2) Mounting board
* Assigned for the range of continuous
mounting from I/O slot 1 (I/O1) Mounting
board
• Reference 2 Priority of extension I/O ports at
automatic assignment
Port No.
(No.1000 to 3999/
No.4000 to 6999)
1) Network I/F Module 2
2) Extension I/O Unit
3) IA Net
Note If the automatic assignment is selected, the input port is assigned to an input port area
(No. 0 to 299).
The output port is assigned to the output port area (No. 300 to 599).
If the fixed assignment is selected, the user will manually assign the input to either of the
standard input port area (No. 0 to 299) or extension input port area (No. 1000 to 3999).
For the output port, the user will manually assign the output to either the standard output
port area (No. 300 to 599) or the extension output port area (No. 4000 to 6999).
