6. Maintenance and Inspection
51
Replace the stainless steel sheet with the procedures from 6.5.1 to 6.5.3.
Adjust the tension of the stainless steel sheet with the procedures in 6.5.2 and 6.5.3.
6.5.1 Replacement Procedure for Stainless Steel Sheet
Replace the degraded stainless steel sheet with a new one by following the steps described below.
1) Check a new stainless steel sheet to confi rm absence of scratches or soiling.
2) Loosen the screws affixing the damaged stainless steel sheet with a 7mm-sized hex wrench,
and remove the retainer plates.
3) Connect the damaged stainless steel sheet and new stainless steel sheet using adhesive tape.
4) Slowly pull out the damaged stainless steel sheet.
5) Confirm that the new stainless steel sheet has been installed in the slider.
Slowly pull out
the sheet.
Connect using adhesive tape.
New stainless steel sheet
Connect the damaged stainless steel sheet and new stainless steel sheet using adhesive tape,
and then slowly pull out the damaged stainless steel sheet so that the new sheet takes its
position.
