1. Specifications Check
16
1.2.3 No. of Encoder Pulses
Type No. of Encoder Pulses Lead Length [mm]
H8SS, H8SM 50000 50
H8HS, H8HM 50000 50
L15SS, L15SM 50000 50
1.2.4 Positioning Precision
Type Item Specifications
Positioning Repeatability ±0.005mm
H8SS, H8SM
Lost Motion 0.02mm or less
Positioning Repeatability ±0.005mm
H8HS, H8HM
Lost Motion 0.02mm or less
Positioning Repeatability ±0.005mm
L15SS, L15SM
Lost Motion 0.02mm or less
The values shown above are the accuracy at the delivery from the factory.
It does not include the consideration of time-dependent change as it is used.
