The following shows the entire wiring diagram for a simple digital-only programming console for one
eight bit channel. Channel 0 pinouts shown on the 1/4 J-6 connectors. Add 10 to all pin numbers for
channel 1, 20 for channel 2, and 30 for channel 3. All switches are Single Pole, Double Throw (SPDT)
center off, (optionally momentary one side only). Rear view of actual switches is shown.
to MICRO MACs Input pin #9 (white)
to your show connector pin #9 (white)
from MICRO MACs Output pin #9 (white)
Programming Switch For
Channel 0, Bit 0
to MICRO MACs Input pin #8 (grey)
to your show connector pin #8 (grey)
from MICRO MACs Output pin #8 (grey)
LED
2.2 K resistor
off
Programming Switch For
Channel 0, Bit 1
to MICRO MACs Input pin #7 (violet)
to your show connector pin #7 (violet)
from MICRO MACs Output pin #7 (violet)
Programming Switch For
Channel 0, Bit 2
to MICRO MACs Input pin #6 (blue)
to your show connector pin #6 (blue)
from MICRO MACs Output pin #6 (blue)
Programming Switch For
Channel 0, Bit 3
to MICRO MACs Input pin #5 (green)
to your show connector pin #5 (green)
from MICRO MACs Output pin #5 (green)
Programming Switch For
Channel 0, Bit 4
to MICRO MACs Input pin #4 (yellow)
to your show connector pin #4 (yellow)
from MICRO MACs Output pin #4 (yellow)
Programming Switch For
Channel 0, Bit 5
to MICRO MACs Input pin #3 (orange)
to your show connector pin #3 (orange)
from MICRO MACs Output pin #3 (orange)
Programming Switch For
Channel 0, Bit 6
to MICRO MACs Input pin #2 (red)
to your show connector pin #2 (red)
from MICRO MACs Output pin #2 (red)
Programming Switch For
Channel 0, Bit 7
ground from MICRO MACs Output pin #1 (brown)
+15 VDC from MICRO MACs Output pin #10 (black)
+15 VDC to MICRO MACs Input pin #10 (black)
+15 VDC to your show connector pin #10 (black)
ground to your show connector pin #1 (brown)
ground to MICRO MACs Input pin #1 (brown)
(on)
LED (fuse indicator - lit if fuse is OK)
2.2 K
resistor
playback
playback
playback
playback
playback
playback
playback
playback
LED
2.2 K resistor
off
LED
2.2 K resistor
off
LED
2.2 K resistor
off
LED
2.2 K resistor
off
LED
2.2 K resistor
off
LED
2.2 K resistor
off
LED
2.2 K resistor
off
(on)
(on)
(on)
(on)
(on)
(on)
(on)
