- Double Show using 27C512 Eprom -
To configure a Playback-only Micro MACs Brick for use with 27C512 Eprom Chips for a capaci-
ty of two 32,768 (32K) banks. The Eprom chips must be ÔSouthÕ justified, leaving four unused holes
at the top of each socket.
0
channel
U13
1
channel
U14
2
channel
U15
3
channel
U16
U17 (ch 0)
U18 (ch 1) U19 (ch 2)
U20 (ch 3)
JP3
JP5
JP2 JP4
JP1
DMX-
512
in/out
DMX-512 Address
DipSwitch
1
DMX heart Brick Run DMX data DMX Error
U24
JP6
27C512 27C512 27C512 27C512
- Double Show using 27C020 Eprom -
To configure a Playback-only Micro MACs Brick for use with 27C020 Eprom Chips for a capaci-
ty of two 131,072 (128K) banks.
0
channel
U13
1
channel
U14
2
channel
U15
3
channel
U16
U17 (ch 0)
U18 (ch 1) U19 (ch 2)
U20 (ch 3)
JP3
JP5
JP2 JP4
JP1
DMX-
512
in/out
DMX-512 Address
DipSwitch
1
DMX heart Brick Run DMX data DMX Error
U24
JP6
27C020 27C020 27C020 27C020
