Gilderfluke&Co 'Dumb' Brick Animation Control System User Manual
Page 13
- 27C512 Eprom -
To configure a Playback-only Micro MACs Brick for use with 27C512 Eprom for a capacity of
65,536 (64K) frames The Eprom chips must be ÔSouthÕ justified, leaving four unused holes at the
top of each socket.
0
channel
U13
1
channel
U14
2
channel
U15
3
channel
U16
U17 (ch 0)
U18 (ch 1)
U19 (ch 2)
U20 (ch 3)
JP3
JP5
JP2
JP4
JP1
DMX-
512
in/out
DMX-512 Address
DipSwitch
1
DMX heart
Brick Run
DMX data
DMX Error
U24
JP6
27C512
27C512
27C512
27C512
- 27C010, 27C020, 27C040 OR 27C080 Eprom -
To configure a Playback-only Micro MACs Brick for use with:
27C010 Eprom for a capacity of 131,072 (128K) frames
27C020 Eprom for a capacity of 262,144 (256K) frames
27C040 Eprom for a capacity of 524,288 (512K) frames
27C080 Eprom for a capacity of 1,048,576 (1024K) frames
0
channel
U13
1
channel
U14
2
channel
U15
3
channel
U16
U17 (ch 0)
U18 (ch 1)
U19 (ch 2)
U20 (ch 3)
JP3
JP5
JP2
JP4
JP1
DMX-
512
in/out
DMX-512 Address
DipSwitch
1
DMX heart
Brick Run
DMX data
DMX Error
U24
JP6
27C010
27C020
27C040
27C080
27C010
27C020
27C040
27C080
27C010
27C020
27C040
27C080
27C010
27C020
27C040
27C080
