Gilderfluke&Co 'Dumb' Brick Animation Control System User Manual
Page 18
- Stop or End of Memory Flag -
The Micro MACs Brick has five wire -ORed inputs which can be jumpered to set the ÔStop or
End of MemoryÕ flag when all of these pins go to a high state (floating is also considered a ÔhighÕ
state). The Dipswitches can be configured to stop and/or reset the Brick when this flag is set. The
typical use for this input is to:
A)
Set flag to stop or reset at the end of the installed memory
B)
Set flag to stop or reset at a certain frame is reached in the show
C) Set flag to stop or reset when a certain combination of up to five data bits are set
To set this flag at the following frame numbers, install the jumpers as shown:
- Stop/Reset at 1024 (1K) Frames -
0
channel
U13
1
channel
U14
2
channel
U15
3
channel
U16
U17 (ch 0)
U18 (ch 1)
U19 (ch 2)
U20 (ch 3)
JP3
JP5
JP2
JP4
JP1
DMX-
512
in/out
DMX-512 Address
DipSwitch
1
DMX heart
Brick Run
DMX data
DMX Error
U24
JP6
G
ILDERFLUKE
& C
O
. ¥ 205 S
OUTH
F
LOWER
S
T
. ¥ B
URBANK
, C
ALIF
. 91502-2102 ¥ 818/840-9484 ¥
FAX
818/840-9485
