Edge Connector: All of the connections to and from Playback-only Micro MACs Brick Cards are
available on the 60 position edge connector. You can use an Insulation Displacement Edge
(IDE) connector if you arenÕt going to be using one of our card cages:
output wire # Edge pin # color wire function
J8 Black (common) 1 brown Micro MACs J8 Common (black) input
J8 White (Reset) 2 red Micro MACs J8 Reset (white) input
J8 Red (Stop) 3 orange Micro MACs J8 Stop (red) input
Serial Port red #3 4 yellow TxD + out from Smart Brick Brain
J8 Green (Start) 5 green Micro MACs J8 Start (green) input
Serial Port Black #2 6 blue TxD - out from Smart Brick Brain
J8 Yellow (Status Out) 7 violet Micro MACs J8 Status Out (yellow) output
Serial Port Yellow #5 8 gray Rx + in to Smart Brick Brain
J8 Blue (Clock/Dbl. Show) 9 white Micro MACs J8 Clock/Double Show (blue) input
Serial Port green #4 10 black Rx -in to Smart Brick Brain
#1 11 brown J6 out channel 0 Ground
#2 12 red J6 out channel 0 bit 7
#3 13 orange J6 out channel 0 bit 6
#4 14 yellow J6 out channel 0 bit 5
#5 15 green J6 out channel 0 bit 4
#6 16 blue J6 out channel 0 bit 3
#7 17 violet J6 out channel 0 bit 2
#8 18 gray J6 out channel 0 bit 1
#9 19 white J6 out channel 0 bit 0
#10 20 black J6 out channel 0 + Supply
#11 21 brown J6 out channel 1 Ground
#12 22 red J6 out channel 1 bit 7
#13 23 orange J6 out channel 1 bit 6
#14 24 yellow J6 out channel 1 bit 5
#15 25 green J6 out channel 1 bit 4
#16 26 blue J6 out channel 1 bit 3
#17 27 violet J6 out channel 1 bit 2
#18 28 gray J6 out channel 1 bit 1
#19 29 white J6 out channel 1 bit 0
#20 30 black J6 out channel 1 + Supply
#21 31 brown J6 out channel 2 Ground
#22 32 red J6 out channel 2 bit 7
#23 33 orange J6 out channel 2 bit 6
#24 34 yellow J6 out channel 2 bit 5
#25 35 green J6 out channel 2 bit 4
#26 36 blue J6 out channel 2 bit 3
#27 37 violet J6 out channel 2 bit 2
#28 38 gray J6 out channel 2 bit 1
#29 39 white J6 out channel 2 bit 0
#30 40 black J6 out channel 2 + Supply
#31 41 brown J6 out channel 3 Ground
#32 42 red J6 out channel 3 bit 7
#33 43 orange J6 out channel 3 bit 6
#34 44 yellow J6 out channel 3 bit 5
#35 45 green J6 out channel 3 bit 4
#36 46 blue J6 out channel 3 bit 3
#37 47 violet J6 out channel 3 bit 2
#38 48 gray J6 out channel 3 bit 1
#39 49 white J6 out channel 3 bit 0
#40 50 black J6 out channel 3 + Supply
black 51 brown power supply ground
black 52 red power supply ground
black 53 orange power supply ground
black 54 yellow power supply ground
black 55 green power supply ground
red 56 blue + power supply input
red 57 violet + power supply input
red 58 gray + power supply input
red 59 white + power supply input
red 60 black + power supply input
