Cleaning the Sensor Optics,
Continued
Step Action
1 Remove the three thumbscrews from the sensor cover.
2 Remove the sensor cover.
3 Remove the sampling head from the bottom of the sensor.
4 Inspect the sensor cover for residual dust.
Note: Use one of the following methods to clean the surface.
• Blow the dust away with low pressure air, or,
• Wipe with a soft lint-free cloth.
5 Inspect the glass lens covers for dust.
Note: Use one of the following methods to clean the glass lens.
• Blow the dust away with low pressure air, or,
• Use a small amount of isopropyl alcohol and wipe with cotton
swabs.
CAUTION: Do not spill any alcohol into the internals of the
Haz-Dust IV.
6 Replace the sampling head.
7 Replace the sensor cover.
8 Tighten the three thumbscrews snugly into place.
Continued on next page
