Sampling,
Continued
L o c : 0 0 1 E X P O S U R E
D a t e : T U E 1 2 - J A N - 9 7
T i m e : 0 7 : 2 3 : 3 8
C o n c : T 2 . 7 5 m g / m 3
D a t a R e c o r d S c r e e n
A
B
C
Figure 3.10. The Data Record Screen. The table below describes the
diagram details.
Detail Explanation
A Indicates Location Code of data being sampled. A record
should be kept of the site that corresponds to each location
code.
Note: See page 3-13 for explanation of location codes.
B Particulate type being sampled.
T = Thoracic
R = Respirable
I = Inhalable
C Concentration. A negative number may indicate the baseline of
the unit is not set to zero and the Auto-Zero process should be
performed (page 3-7).
Ending the
Sampling
process Press ENTER to stop data collection and return to the Main Menu.
Note: If the security feature was used during sampling a confirmation screen
will require the security code of 1209 to be entered.
3 - 12
