Typical system diagram, Slimzone deluxe 12 – Robertshaw SlimZone Deluxe ZONE CONTROL SYSTEM User Manual
Page 16
SlimZone Deluxe
12
HVAC SYSTEM
Discharge
Air Limit
Control
Bypass Damper
Zone
Dampers
From HVAC panel
to Logic panel
Logic Panel and
Zone Damper
Transformers
Zone
Thermostats
DELUXE
LOGIC
PANEL
2701-002
Heat/Auto/Cool
Selector Switch
(Optional)
Emergency Heat
Switch
(Optional)
System Clock
(Optional)
High BP (Balance Point Control)
ODT
(Optional)
LOW BP (Balance Point Control)
ODT
(Optional)
2 ZONE EXPANDER
MODULE 2701-003
2 ZONE EXPANDER
MODULE 2701-003
10. TYPICAL SYSTEM DIAGRAM
