Robertshaw 300-229 - Manual

Features and Benefits
Contemporary Design
Compliments any décor.
Large Digital Display
Makes viewing and setting the temperature easy
and accurate.
Auto Changeover
Automatically switches into heat or cool mode. Prevents
having to manually change system from heat to cool.
3-Hour Temporary Program Override
Allows for manual temperature adjustment.
2 or 4 Events Per Day
Customizable for any environment.
Occupancy Terminal
A set of dry contacts allows control of fresh air dampers,
security lighting, etc., for occupied and unoccupied periods.
LED Indicators
Two customizable LEDs for selectable fault indicators.
EEPROM Memory
Electronic memory storage with no batteries to replace.
Automatic Compressor Short Cycle Protection
A system safeguard. Reduces wear and tear of
HVAC equipment.
Progressive Recovery
Allows gradual recovery from setback periods
for increased energy savings.
Lockable Keypad and Front Cover
Two levels of security against unwanted tampering.
Remote Sensor Capable
Connects to optional remote indoor or outdoor sensors
for optimal comfort.
7 Day Programmable
2 Heat / 2 Cool
Elegantly Sophisticated
The Robertshaw 300-229 takes comfort to the next level with
state-of-the-art control for commercial applications.
Controlling your indoor environment is easy with standard
features such as Auto Changeover, independent switching
circuitry, Programmable Fan and selectable 2 or 4 events per
day. Coupled to EEPROM permanent memory storage and a
tamper-free control setting, this model provides worry-free
operation.
Conventional control in an unconventional package. When you
select a Robertshaw thermostat, you’ve made the choice of an
industry partner that’s been making quality products for over
100 years.
Technical service available:
1-800-445-8299
M-F 7:30 a.m. - 5:30 p.m. CST
300-229
DELUXE
PROGRAMMABLE
THERMOSTAT
W
A R R A N T Y
T
W
O Y E A
R
2
®
G
GAS
E
ELECTRIC
