Robertshaw 9415 User Manual

User's manual, Quick start installation

background image

DIGITAL

NON-PROGRAMMABLE

THERMOSTAT

9415

ELECTRIC

E

GAS

G

OIL

O

NeW

2 Heat / 2 Cool

User's Manual

Quick Start
Installation

Application

The Robertshaw 9415 is a multi-stage thermostat designed to control
24 VAC gas or electric two-stage heating and two-stage cooling systems.

Features

• Summer and winter setpoints

• Large back lit display

• Adjustable 1

st

stage temperature differential: .5°F to 3.0°F

(0.5°C to 1.5°C)

• Adjustable 2

nd

stage temperature differential: 1° to 6°F (.5°-3°C)

• Compressor short cycle protection

• Accuracy within ±1°

• Zone system compatible as a master thermostat

• Permanent memory retention

• Fahrenheit/Celsius display option

• Adjustable from 45°F to 90°F (7°C - 32°C)

• Quick wire terminal block

• Automatic heating shutdown if temperature exceeds 94°F (34°C)

1

110-1043B
