Installation Instructions
Toyota Sequoia
Part Numbers:
44089
75126
Hitch Shown In Proper Position
Equipment Required:
Wrenches: 18mm, 3/4, 7/8
Drill Bits: None
2
Frame
1
. Lower spare tire.
2. Raise hitch into position, making sure to slide saddle bar under fascia, and attach side bracket fasteners as shown. Do not tighten.
3. Install fasteners to saddle bar and tighten all fasteners.
4. Raise spare tire into position.
Rev. B
6-27-06
N75126
Sheet 1 of 1
z
2001, 2002, 2006 Cequent Towing Products
Bolt 1/2-13 X 3.50
Qty. (4)
3
Hex Nut 1/2-13
Qty. (4)
5
Conical Washer 1/2”
Qty. (10)
2
Block
Qty. (4)
4
Bolt M12 X 1.25 X 45mm
Qty. (6)
1
Tighten all M12 CL8.8 fasteners with torque wrench to 68 Lb.-Ft. (92 N*M)
Note: check hitch frequently, making sure all fasteners and ball are properly tightened. If hitch is removed, plug all holes in trunk pan or other body panels to
prevent entry of water and exhaust fumes. A hitch or ball which has been damaged should be removed and replaced. Observe safety precautions when working
beneath a vehicle and wear eye protection. Do not cut access or attachment holes with a torch.
This product complies with safety specifications and requirements for connecting devices and towing systems of the state of New York, V.E.S.C. Regulation V-5
and SAE J684.
Fastener Kit: F75126
Do Not Exceed Lower of Towing Vehicle
Manufacturer’s Rating or
500 (227 Kg)
5000 (2270 Kg)
Weight Carrying
Ball Mount
650 (295 Kg)
6500 (2951 Kg)
Weight Distributing
Max Tongue
WT (LB)
Max Gross
Trailer WT (LB)
Hitch type
Wiring Access Location: SUV7
Tighten all 1/2 GR5 fasteners with torque wrench to 75 Lb.-Ft. (102 N*M)
Existing weldnuts
both sides
Saddle bar
English
Metric
1
2
5
3
4
Fascia
Frame
Fascia
Bolt head marking
Bolt head marking
