Installation Instructions
Infinity JX
Nissan Pathfinder
Part Numbers:
75750
44679
87625
Hitch Shown In Proper Position
Equipment Required:
Wrenches: 18mm
Drill Bits: None
Frame and Existing weld nuts
Fastener Kit: 75750F
Do Not Exceed Lower of Towing Vehicle
Manufacturer’s Rating or
Hitch type
Max Gross
Trailer WT (LB)
Max Tongue
WT (LB)
Weight Distributing
Do not use
with spring bars
Do not use
with spring bars
Weight Carrying
Ball Mount
3500 (1589 Kg) 525 (238 Kg)
Wiring Access Location: SUV1, SUV2
Tie Down Bracket
Fascia
Frame rail
1. Remove Tie down brackets and return to customer.
2. Raise Hitch into place and Install the six (6) M12 fasteners and Conical Washers as shown above.
z
2012, 2013 Cequent Performance Products Sheet 1 of 3 75750N 2-25-13 Rev. B
1 1 1 1 Qty. (6) Bolt M12 X 1.25 X 35mm 2 2 2 2 Qty. (6) Conical Washer
Tighten all M12 Cl8.8 fasteners with torque wrench to 68 Lb.-Ft. (92 N*M)
Note: check hitch frequently, making sure all fasteners and ball are properly tightened. If hitch is removed, plug all holes in trunk pan or other body panels to
prevent entry of water and exhaust fumes. A hitch or ball which has been damaged should be removed and replaced. Observe safety precautions when working
beneath a vehicle and wear eye protection. Do not cut access or attachment holes with a torch.
This product complies with safety specifications and requirements for connecting devices and towing systems of the state of New York, V.E.S.C. Regulation V-5
and SAE J684.
2
1
Note: Fasteners typical both sides
