Ransburg Evolver Solvent Robot Applicator 79190-XXXXXXXX - Manual (Page 76)

Tubing Material Tubing Size Item #
P1 Paint #1 Clear 5/16" OD X 3/16" ID 29
P2 Paint #2 Black Urethane/Poly 5/16" OD X 3/16" ID 29
P1 Paint #1 Clear 3/8" OD X 1/4" ID 29
P2 Paint #2 Black Urethane/Poly 3/8" OD X 1/4" ID 29
SOL Solvent Black Urethane/Poly 3/8" OD X .187" ID 28
P1T Paint #1 Trigger Green Nylon 3/16" OD X .050" Wall 24
P1D Paint #1 Dump Gray Nylon 3/16" OD X .050 Wall 25
P2T Paint #2 Trigger Natural Nylon 3/16" OD X .050" Wall 17
P2D Paint #2 Dump Black Nylon 3/16" OD X .050" Wall 31
TP Trigger Pilot Black Nylon 3/16" OD X .050" Wall 27
DL Dump Line Natural .313" OD X .188" ID 19
RP Regulator Pilot Natural Nylon 3/16" OD X .050" Wall 17
ST Solvent Trigger Blue Nylon 3/16" OD X .050" Wall 26
F Fan Air Black Nylon 3/8" OD X .250" ID 23
A Atomization Air Natural Nylon 3/8" OD X .250" ID 16
LV Low Voltage Cable Black N/A N/A 2, 32
SIGNAL IDENTIFICATION TABLE - ENGLISH
Abbr. Description Color
Tubing Material Tubing Size Item #
P1 Paint #1 Clear 8mm OD X 6mm ID 29
P2 Paint #2 Clear 8mm OD X 6mm ID 29
SOL Solvent Clear 8mm OD X 6mm ID 29
P1T Paint #1 Trigger Green Nylon 4mm OD X .106" ID 24
P1D Paint #1 Dump Silver Nylon 4mm OD X .106" ID 25
P2T Paint #2 Trigger Natural Nylon 4mm OD X .106" ID 17
P2D Paint #2 Dump Black Nylon 4mm OD X .106" ID 31
TP Trigger Pilot Yellow Nylon 4mm OD X .106" ID 27
DL Dump Line Clear 8mm OD X 6mm ID 29
RP Regulator Pilot Natural Nylon 4mm OD X .106" ID 17
ST Solvent Trigger Blue Nylon 4mm OD X .106" ID 26
F Fan Air Black Nylon 10mm OD X 8mm ID 23
A Atomization Air Natural Nylon 10mm OD X 8mm ID 16
LV Low Voltage Cable Black N/A N/A 2, 32
SIGNAL IDENTIFICATION TABLE - METRIC
Abbr. Description Color
Evolver Solventborne Robotic Atomizers - Parts Identification
