EVOLVER GUN SELECTION GUIDE
Table A = Atomization Technology
0 = Air Spray
1 = HVLP
Table B = Spray Head Configuration
0 = 60° Single Head
1 = 90° Single Head
2 = 60° Dual Head
3 = 90° Dual Head
Table C = Purge/Regulator Configuration
0 = Single Purge / No Regulator
1 = Dual Purge / No Regulator
2 = Single Purge / With Fluid Regulator
3 = Dual Purge / With Fluid Regulator
4 = Single Purge / No Regulator / Non-Electrostatic
5 = Dual Purge / No Regulator / Non-Electrostatic
6 = Single Supply / No Valves / Short Fluid Tube
Table D = Robot Adapter Plate
0 = No Adapter
1 = ABB
2 = Fanuc P-155
3 = Fanuc P-200
4 = Adapter (KAWASAKI-KE610L)
5 = Adapter (MOTOMAN-PX2850)
6 = Adapter (MOTOMAN-PX2900)
Table E = Fluid Hose Type
0 = No Fluid Hose
1 = 3/16" ID Non-Shielded
2 = 3/16" ID Shielded
3 = 1/4" ID Non-Shielded
4 = 1/4" ID Shielded
5 = 6 mm ID Non-Shielded
79190 - A B C D E FF G
