Ransburg, Intermediate gun housing - parts list (figure 12) – Ransburg Evolver Solvent Robot Applicator 79190-XXXXXXXX User Manual
Page 44
3
79169-00
Valve Manifold Assembly
1
4
79177-00
Fluid Fitting Assembly
1
5 7554-10
O-Ring
2
6
77508-00
Airbolt, Machined
2
7 7554-11
O-Ring
4
8
77509-00
Threaded Stud
2
9
79136-00
Upper Manifold
1
10 79001-05
O-Ring
4
11
79160-00
Retaining Screw
2
14
70591-01
Fluid Fitting Nut
1
15
70606-01
Front Tube Ferrule
1
16
70607-01
Back Tube Ferrule
1
17
SSF-2052
Set Screw
1
18
79134-00
Connecting Rod
2
19
79135-00
Triggering Tie Rod
2
21
79166-00
Air Connector
2
23
79010-00
HP-404 Cascade Assembly
1
25
78449-00
Fluid Fitting
1
26
EMF-202-04
Back Tube Ferrule
1
27
EMF-203-04
Front Tube Ferrule
1
29
78450-00
Coiled Tube
1
34 79209-00
O-Ring
1
35 7554-07
O-Ring
4
Item #
INTERMEDIATE GUN HOUSING - PARTS LIST (Figure 12)
Part #
Description
Qty
