their mating parts (see Figure 9).
7. The o-ring [16] should be inserted into
the front of the bushing [14] and one of the
o-rings [15] installed onto the outside groove
before the
bushing is installed.
8. Reassemble the remaining parts, as shown in
Figure 9, making sure that the alignment tab on
the bushing [14] lines up with the align groove in
the body [19].
9. Torque the seal carriage [13] to 30-35 lbs•in
(4.0-4.5 Nm).
10. If the u-cup needs to be replaced, assemble
on piston plate [9] and push both onto shaft,
tighten securely with piston nut [7], and install in
body as one assembly.
11. Assemble the remainder of the gun head as
stated earlier.
12. If the locking tab plug connection [24]
needs to be replaced, first remove the electrode
spring connector [23] by pulling straight out with
a needle nose pliers. If removed, the spring wire
should be replaced.
13. Remove socket head screw [22] and connec-
tion plug [24] from body.
14. Replace conductive compressable contact
[25] if necessary.
15. Reinstall the connection plug [24] into the
body, making sure the tabs on the bottom align
with the notches in the body [19].
16. Insert and tighten the screw [22], making sure
the tabs remain inside the notches [24] in the body.
17. Insert the spring electrode wire [23] through
the hole in the screw using a needle nose pliers on
the straight wire portion. Carefully rotate and
push the wire through the screw hole and into the
compressable contact until the spring contacts the
screw head.
>
Use Caution as NOT TO scratch or raise
burrs on inside diameters of the parts.
C A U T I O N
!
Evolver Solventborne Robotic Atomizers - Maintenance
