TABLE A
ATOMIZATION TECHNOLOGY
0
1
Dash
No. Description
Conventional Spray
HVLP Spray
"Z"
79138-01
79138-02
TABLE B
HEAD CONFIGURATION
0
1
2
3
Dash
No. Description
60° Single Head
90° Single Head
60° Double Head
90° Double Head
"Y"
LSFA0027-00
LSFA0027-00
79206-00
79206-00
TABLE D
ROBOT ADAPTERS
0
1
2
3
4
5
6
Dash
No. Description
No Adapter
"ABB" Robot Adapter
"FANUC" P-155 Robot Adapter
"FANUC" P-200 Robot Adapter
Adapter (Kaswsaki-KE610L)
Adapter (Motoman-PX2850)
Adapter (Motomanu-PX2900)
"S"
----
79107-00
78983-00
79131-00
A10847-00
A10848-00
A10849-00
1 Table B - "Y" Screw, #10-32, Fiberglass, Fillister Head, Machined
2 Table A - "Z" Spray Head Assembly
4 79179-00 Assembly, Mounting Block 60° Single Head
5 79180-00 Assembly, Mounting Block 90° Single Head
6 79243-00 Assembly, Mounting Block 60° Dual Head
7 79224-00 Assembly, Mounting Block 90° Dual Head
8 79175-01 Single Purge, No Regulator
9 79175-02 Dual Purge, No Regulator
10 79175-03 Single Purge, W/Regulator
11 79175-04 Dual Purge, W/Regulator
12 Table D - "S" Robot Adapters
13 Table FF - "W" Rear Manifold Assembly
14 Table G - "X" Power Supply (Not Shown)
16 79175-05 Single Purge, No Regulator, Non-Electrostatic
17 79175-06 Dual Purge, No Regulator, Non-Electrostatic
18 79175-07 Single Supply, No Valves, Short Tube
Item #
79190-XXXXXXXX GUN ASSEMBLY - PARTS LIST (Figure 18)
Part # Description
Evolver Solventborne Robotic Atomizers - Parts Identification
52
