Tubing Manifolds (Metric):
A10853-01 7.62m
A10853-02 15.24m
A10853-03 22.86m
A10853-04 30.48m
Robot/Mounting Compatibility:
All hollow wrist robots
Gun Control Unit:
MicroPak Control Unit - LECU5004-31
Stand-Alone Control Unit - A10406
Operating Temperature Range:
55°F (12.8°C) - 131°F (55°C)
Weight
Single-Headed:
60° 9.9 lbs. (4.5 Kg)
90° 9.6 lbs. (4.4 Kg)
Dual-Headed:
60° 10.4 lbs. (4.7 Kg)
90° 10.4 lbs. (4.7 Kg)
Manifold:
79175-XX 1.7 lbs. (.77 Kg)
(No tubing or cable)
Length
Single-Headed:
60° 17" (43.18cm)
90° 14 1/2" (36.83 cm)
Dual-Headed:
60° 16-1/4" (41.28cm)
90° 13" (33.02cm)
Tubing Manifolds (English):
79156-01 25 ft.
79156-02 50 ft.
79156-03 75 ft.
79156-04 100 ft.
SPECIFICATIONS
The MicroPak power supply control unit provides
a low voltage signal through the robot manifold
to the spray gun. The high voltage cascade lo-
cated within the gun converts the low voltage DC
signal to a high voltage electrostatic output. (See
the most current "MicroPak" and "Stand-Alone
Evolver MicroPak Controller" Service Manuals for
details of the control unit.)
Atomizing Air
Fan Air
Trigger Air
Regulator Pilot
Dump Pilot
Fluid:
Polyethylene
Dump:
Robot Manifold Tubing Requirements
English Metric
3/8"
3/8"
3/16"
3/16"
3/16"
1/4" or 3/16" ID
(Shielded &
Non-Shielded
1/4" or 3/16" ID
(Shielded & Non-
Shielded)
3/16" ID
10mm OD Nylon
10mm OD Nylon
4mm OD Nylon
4mm OD Nylon
4mm OD Nylon
6mm
(Non-Shielded)
6mm
Environmental/Physical
Electrical Requirements
Output Voltage: 30-100 kV
Output Range: 0-85 µA
Paint Flow Rate:
Variable to 1500 cc/min. (Depending on
viscosity & configuration)
Trigger Response Time: 150m sec. Open
220m sec. Closed
Operating Air Pressures
Atomizing Air: 100 psig (6.9 bar) max.
Fan Air: 100 psig (6.9 bar) max.
Trigger Air: 70 psig min./100 psig
(4.8 - 6.9 bar) max.
Regulator Pilot: 0 psig min./100 psig
(0 - 6.9 bar) max.
Dump Pilot: 70 psig min./
100 psig max.
(4.8 - 6.9 bar)
Operating Fluid
Pressure: 200 psig (13.8 bar) max.
100 psig (6.9 bar) max.
Regulated (with on-board
regulator)
