NOTES
damage will occur. Push the diaphragm assembly
down in valve body aligning the screw holes.
9. Tighten the regulator bonnet [10] to the block
assembly [1] securely with the six (6) screws [11]
in an alternating 18 0° method. Reinstall the tube.
10. To remove the complete regulator assembly
from the gun, remove the coiled tube [29] by
removing the tubing nut and ferrules [25], [26],
and [27].
11. Remove the regulator assembly from the fluid
inlet fitting [13] by removing the nut and ferrules
[13], [14], and [15] and pull up and out.
12. Reinstall the coiled tube [29] as shown in Figure
15; one of the coils of the tube must be wrapped
around the cascade as shown. Re-attach the pilot
tube [39] to the regulator bonnet.
13. Reassemble the remainder in reverse order.
>
When replacing the needle seat, be
cautious so that the plastic threads are
not stripped by cross threading.
NOTE
Evolver Solventborne Robotic Atomizers - Maintenance
45
Ransburg
AA-03-02.12
