Ransburg – Ransburg Vector Solo AA90 79698 User Manual

Page 29

Vector Solo AA90 Applicators - Maintenance

Ransburg

AH-08-04.2

1. Turn the paint and air supplies OFF. Relieve

both fluid and air pressures. Set the trigger stop

lever.

2. Unscrew the air cap retaining ring completely

from the barrel.

3. With the front of the barrel tilted downward,

remove the air cap and fluid nozzles.

4. Clean all parts in a suitable solvent and examine

for wear and damage. To clear the fluid nozzle

orifice, blow compressed air through the tip in the

opposite direction of flow. Soaking in solvent and/

or brushing may also be necessary to clean the

orifice. Replace as necessary.

5. Clean all exterior surfaces of the applicator

with a rag and a suitable solvent.

6. Assemble the parts in reverse order of disas-

sembly.

Ensure supply pressures have been

bled to zero prior to servicing the applicator.

Failure to do so may cause personal injury.

If the fluid nozzle is completely clogged,

triggering the applicator will not release the

pressure. Cover the end of the applicator

with a heavy rag and loosen the nozzle nut

slowly into a grounded catch container.

Any broken or damaged components

should be replaced. Any damage to the

applicator may result in

UNSAFE operating

conditions.

A wire brush or metal tools must

NEVER

be used.

NEVER use a cleaning tool that

is harder than the plastic parts. If a deposit

cannot be removed with solvent and a rag or

the soft brush, soak the part in solvent

ONLY

until the deposit can be removed!

NEVER

soak the applicator body, barrel, or hook

transformer!

NEVER wrap the applicator, associat-

ed valves and tubing, and supporting hard-

ware in plastic to keep it clean. A surface

charge may build up on the plastic surface

and discharge to the nearest grounded ob-

ject. Efficiency of the applicator will also be

reduced and damage or failure of the appli-

cator components may occur.

WRAPPING

THE APPLICATOR IN PLASTIC WILL VOID

WARRANTY.

1. Remove applicator from the worksite after fol-

lowing the "Flush Procedure".

Ensure all pressure have been bled from

the fluid and air line prior to disconnection.

W A R N I N G

C A U T I O N

W A R N I N G
