Vector Solo Applicators - Parts Identification
42
(Continued On Next Page)
Item #
VECTOR SOLO SOLVENTBORNE APPLICATOR -
PARTS LIST (Figure 77)
Part # Description Qty
Ransburg
1 Table D - "D2" Nozzle, Fluid, 1.4mm 1
2 80119 Assembly, Barrel, Vector Solo 1
3 79600-00 Cascade Assembly 1
4 79832-00 Gasket, Barrel 1
5 79869-00 Stem, Male QD (Included with QD ordered Models) 1
6 Table D - "D1" Cap, Air, 65R 1
7 79724-00 Nut, Retaining, Air Nozzle 1
8 LSOR0005-17 O-Ring, PTFE Encapsulated 1
9 79385-00 Nut, Connector, Hose 2
10 EMF-202-05 Ferrule, Back 3/8" Tube 2
11 EMF-203-05 Ferrule, Front 3/8" Tube 2
12 79878-02 Tube, Fluid Inlet, 3.2mm ID (.125") 1
79878-03 Tube, Fluid Inlet, 3.4mm ID (.250") 1
Table E - "E" Tube, Fluid, Inlet, 2.4mm ID (.093"), 232mm, 9 1/8" Lg. 1
(Standard W/Applicator)
13 79816-00 Assembly, Rear Cover 1
14 79798-03 SHCS, M5 X 30" 1
15 79799-01 Socket Head Cap Screw, M4 X 25mm 4
16 79798-02 Socket Head Cap Screw, M5 X 80mm 2
17 Table C - "C" Assembly, Trigger 1
18 79454-00 Screw, Trigger Retention 2
19 79762-00 Nut, Fluid Jam, Front 1
20 79774-00 Spring, Air Valve Return 1
21 79701-00 Hook, Molded 1
22 79799-02 SHCS, M4 X 30mm 1
23 Table A - "A" Assembly, Air Hose, Solo (10, 20, and 30m Lengths) 1
24 79833-00 Assembly, Handle, Vector Solo 1
(Includes Items 33, 34, 35, 36, 37, and 38)
24A 79833-01 Assembly, Handle Only 1
25 79835-00 Assembly, Power Module 1
(Includes Items 39, 40, 41, 42, and 43)
26 79768-00 Nut, Fluid Jam, Spring Guide 1
27 78636-00 Spring 1
28 79789-00 Assembly, Rear Fluid Adjustment 1
29 79781-00 Seal, Adjustment Bushing 1
30 79837-00 Gasket, Handle to Power Module 1
31 Table D - "D3" Pressure Reducer, Atomizing Air, Vector Solo (Yellow) 1
32 79853-00 Kit, Shaft Assembly, 2 Piece Needle, Vector Solo 1
33 79760-00 Seal, Air Valve 1
34 79001-09 O-Ring, Solvent Proof 1
35 79770-00 Cartridge, Air Valve 1
36 79759-00 Assembly, Fan Air Adjust Valve 1
37 79772-00 Assembly, Air Valve 1
38 79847-00 Valve, Atom Adjust 1
79847-01 Plug, Atom (Std. installed in applicator) 1
39 79755-00 Fluid Inlet 1
AH-08-01.10
