Vector Solo Applicators - Operation
18
2. Turn off supply air.
3. Discharge fluid into appropriate grounded me-
tallic container.
Figure 13: Applicator Supply Air - Off
Figure 14: Applicator Flush Out
4. Load next color or remove applicator from in-
stallation as required.
NOTES
1 - Main Air Supply
2 - Closed Ball Valve
Supply air to the applicator must be in-
terlocked with the solvent supply. Supply air
must be off whenever solvent supply is on.
W A R N I N G
!
Ransburg
AH-08-01.10
