Fairbanks H90-5200-A Digital Instrument - Manual (Page 49)

NOTES:
1. String 0 only output if polled by ID from computer
2. String 1 only output if time (t) enabled.
3. String 2 only output if date (d) enabled.
4. String 3 only output if time (t) or date (d) enabled.
5. String 4 only output if ID (i) enabled.
6. String 5 only output for Gross display or Net display with Gross/Tare/Net print enabled.
7. String 6 only output for Net display and Gross/Tare/Net print enabled.
8. String 7 only output for Net display
9. LF only output if CR LF print mode selected.
10. X’s indicate numeric data including decimal points. Leading zeroes are replaced with spaces.
11. Y’s indicate alpha-numeric data.
12. Mode (Gross/Net) is output in upper case if no motion on scale (ie. GR) or lower
case if motion on scale (ie. gr).
Remote Display Format
50515 49 Issue #2 4/04
Character Number 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
String 0
Scale ID
SP S C A L E SP X X X CR LF
Note: 1.9.10
String 1
Time
SP Hour Hour : Minute Minute A/P M
Note:2 Ones Ones Tens Ones
String 2
Date
SP M/D M/D - D/M D/M - Y Y
Note: 3 Tens Ones Tens Ones Tens Ones
String 3
CR LF
Notes: 4,9
String 4
ID
SP I D - Y Y Y Y Y Y CR LF
Notes: 5,9,11
String 5
Gross
SP X X X X X X X SP l/k b/g SP G R CR LF
Notes:6,9,10,12
String 6
Tare
SP X X X X X X X SP l/k b/g SP T A CR LF
Notes: 7,9,10,12
String 7
Net
SP X X X X X X X SP l/k b/g SP T A CR LF
Notes: 8,9,10,12
String 8
CR LF
Note: 9
