APPENDIX I: QUICK REFERENCE CHART
Front Panel Program Steps Factory Setting Prompt
1. Displays Program Revision Number “P294-x”
2. Weight Units Selection lb/kg “U”
lb, kg, lb/kg, or custom (no display unit)
2a. Primary Weight Units Selection lb “PU”
(if lb/kg are selected in step 2)
3. Grad Size Selection 0.01 “GSxxxx”
0.0001 to 50
4. Balance/Motion Selection 2.0 “bALx.x”
0.5,1.0,2.0,3.0 divisions
5. AUTO ZERO TRACKING Selection 1.0 divisions “AO x.x”
OFF, 0.5,1.0, 3.0 divisions
6. Auto Zero Time Delay 1 sec “AOtd x”
1 to 6 sec
7. ZERO LIMIT Selection 100% “OL xxx”
+/- 2% or 100% of capacity
8. AUTO TARE Selection 1 “AtArEx”
0 = disabled 1 = enabled
9. KEYBOARD TARE Selection 1 “tArE x”
0 =disabled 1 enabled
10. Display Update Rate Selection 0.5 “SEC x.x”
0.1,0.3,0.5,0.8, 1.0 seconds
11. Digital Filter Selection 2 “FF x”
0 (No filter), 1, 2, 3 or 4 (Mm to Max filter)
12. Scale ID for Polled Serial Communications 0 “id xxx”
0 to 255
13. Time/Date Format Selection: 12 US ‘td xxxx”
12/24 Hours and US/International Date
14. Security Code Selection 0 “S.CodE”
Any number up to 6 digits
0 =disabled
15. Security Level Selection 0 “SL x”
0 = all front panel programming enabled *
1 = limited front panel programming enabled
2 = no front panel programming enabled
* Non-commercial applications only
16. Inhibit Switch Selection 0 “inhS x”
0 = all switches are enabled
1 = one or more front panel switches are disabled
17. Remote Switch 0 “rS 0”
0 = disable, 1 = enable
18, Remote Switch “rS 1”
19. Remote Switch A “rS 2”
20. Remote Switch P “rS3”
50515 38 Issue #2 4/04
