b. The display will show “ENA x”. This is the ENABLE or DISABLE function.
Select 0 to disable output or 1 to enable output. Press ENTER when the
desired choice is displayed.
c. Selecting Output Device
Use the UP and DOWN arrow keys to scroll through the available devices
and press ENTER when the Appropriate devices is displayed. The available
device are:
1) “Pntr” = Printer
Data will be transmitted when the PRINT key is pressed or a remote
print command is received. Computer commands without ID may be
received in this mode. Refer to computer command section for further
details.
2) CPtr P” = Computer - Polled
Computer commands without ID may be received in this mode. Refer
to computer command section for further details.
3) “CPtrPi” = Computer Polled with ID
Computer commands with ID may be received in this mode. Refer to
computer command section for further details.
4) “CPtr A” = Computer - Automatic
Data will be transmitted every display update. Computer
commands with or without ID may be received in this mode. Refer to
computer command section for further details.
5) “dISPLY” = Remote Display
Data will automatically be transmitted every display update. Only
commands that are specific to the Remote Display may be received
over the serial port in this mode.
6.) “P 2642” = PTR 2242 /2642/2742/2844 Label Barcode Printer.
NOTE: If amount of data transmitted exceeds the time available between display
updates, display updates will be lost and the system will appear to slow down. This
can be corrected by decreasing the amount of data transmitted, increasing the baud
rate, or slowing down the display update rate.
d. Select Output Format
If data is being output to a computer or printer, you will be prompted to select
what information to transmit. The display will show “tdi” for time, date and ID.
Any combination of these three items may be selected.
Display meaning
“tdi” time, date, and ID
