4. Interface to Fairbanks Model 50-3925
Using the Printer Handbook included with the Printer set the Printer internal switches
per the following table:
50-3925 Switch Settings Function
SW1 1 0 Baud Rate
2 1 2400 Baud
3 1
4 1 Line Spacing
5 1 8 Lines Per Inch
6 0 Line Feed Select: CR CR LF
7 1 Norm / lnv Print - Normal
8 1 Busy Signal Polarity - High True
9 1 TOF Busy - Busy Sent
1 = Closed, 0 = Open
5. Interface to Fairbanks Model PTR-3950
Using the Printer Handbook included with the Printer set the Printer internal switches
per the following tables:
50-3950 Switch Settings Function
SW 1 1 0 Baud Rate
2 1 2400 Baud
3 1
4 0 Line Spacing
5 0 8 Lines Per Inch
6 0 Line Feed Select: CR CR LF
7 1 Norm / lnv Print - Normal
8 1 Busy Signal Polarity - High True
SW 2 1 1 TOF Busy - Busy Sent
2 0 Not Used
3 0 Normal Print
4 1 Auto Advance - enabled
5 0 Auto Release - disabled
6 0 Enhanced Print - disabled
7 0 Auto Seek - disabled
8 0 Self Test - disabled
1 = Closed, 0 = Open
6. Printer set-up for TMU 295
Use cable Acc 1264 (16157)
OPEN (OFF) CLOSED (ON)
Switch Settings DSW1 = 2,4,5,6,7,8,9,10 1,3
9600 baud, 8 characters, non parity, 1 stop bit, cts=0
7. Printer set-up for TMU 590
Use cable Acc 1264 (16157)
50515 45 Issue #2 4/04
