OPEN (OFF) CLOSED (ON)
Switch Settings DSW1 = 1,2,4,5,6,8 3,7
DSW2 = 1,2,3,4,5,6,7,8 NONE
9600 baud, 8 characters, non parity, 1 stop bit, cts=0
8. 50-3960 Ticket Printer Setup
50-3960 Switch Settings
SW1 = 12345678910
1110000000
9600, None, 8 Bits, Busy=0 Use cable Acc 1264 (3-93081-1)
9. PTR-2242 / 2642 / 2742 / 2844 = "P 2642" Setup:
9600 Baud
No Parity
8 Bits
1 Stop bit
Use Cable Acc-1269 ( 3-93212-2)
The printer must be connected to the 5200-A via cable ACC-1269 and have power ON
before selecting the "P-2642" device. Once selected, choose tdi options, nEt or Gtn
options, Cr/LF options then no bAr/bAr at which time the 5200-A will download data to
the PTR-2642. There will be a short period when the 5200-A will blank, then return to
the gross weigh mode.
General Notes regarding the 5200A's outputs:
1. It is recommended to use a baud rate higher than 300 on com port 2. The 300 baud
rate on that channel may affect the operation of the 5200-A.
2. If display (RMT-140X-A) ( 20mA) is on port 1, and a printer is interfaced to com port
2, the CTS setting of com port 1 must be set to 0.
3. If either the 50-3960 or PTR-3950 ticket printers are interfaced to the 5200-A
indicator, and Autoprint is enabled in either AbA or Abr setpoint modes, a ticket
must be inserted in the printer before the batch is started.
4. When setting up the 140X-A remote display, the remote may show "SUCCESS" and
still not communicate. Check and compare settings manually in both the indicator
and the remote display.
5. If SPon = 1, and using "SP" setpoint mode, any attached relays will be energized
until the setpoint limits are reached. A brief contact may be made when power-up
occurs or certain keys are pressed. Use caution when operating or testing.
Appendix IV: WIRING DIAGRAM for SERIAL OUTPUTS
50515 46 Issue #2 4/04
