1a. Interface to Okidata Model 184 Turbo Serial Printer (Fairbanks Model 50-3921)
Using the Printer Handbook included with the printer set the printer internal
switches per the following table:
Switch block on Controller PCB/Switch
Function 0 1 2 3 4 5 6 7 8
Ascii slashed 0 OFF OFF OFF
Form Length:11 inches OFF ON
Auto Line Feed: OFF OFF
Data Bits: 8 ON
Front Panel: Enabled OFF
Switch Block # 1 on Super Speed Serial Board/Switch #
Function 1 2 3 4 5 6 7 8
Parity: Odd OFF
Without Parity ON
Data Bits: 8 ON
Protocol: Ready/Busy ON
Test Select: Circuit ON
Mode Select: Print ON
Busy Line; DTR “_” ON
Pin #20 ON
Switch Block # 2 on Super Speed Serial Board/Switch #
Function 1 2 3 4 5 6 7 8
2400 Baud** OFF OFF ON
DSR Input Signal: OFF
Inactive
Buffer Threshold:
OFF
256 Bytes
Buffer Signal Timing:
ON
200M5 (Mm)
DTR Signal: Space
ON
After Power On
Not Used*
OFF
*Must remain in OFF position
**Speed Switch 2-1 Switch 2-2 Switch 2-3
19200 ON ON ON
9600 OFF ON ON
4800 ON OFF ON
2400 OFF OFF ON
1200 ON ON OFF
600 OFF ON OFF
300 ON OFF OFF
110 OFF OFF OFF
50515 43 Issue #2 4/04
