08/13 35 51219 -- Rev. 6
Appendix I: Data Output Format
The Continuous Output is as follows:
M M M M Continuous Output with fixed protocol settings.
Char 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
X X X . X X X SP l b SP G R SP SP CR LF EOT
Supplemental Information
1. Leading zeroes are suppressed.
2. Decimal position is based upon graduation size selected.
The RS-232 output format for Gross weight and G.T.N (Gross/Tare/Net/)
weight are as follows:
Prints Gross weight only.
Character 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
SP/- X X X X . X X SP k/l g/b SP G R CR LF
Prints Gross, Tare, and Net weight.
Character 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
SP/- X X X X . X X SP k/l g/b SP G R CR LF
SP/- X X X X . X X SP k/l g/b SP T A CR LF
SP/- X X X X . X X SP k/l g/b SP N T CR LF
Supplemental Information
1. Leading zeroes are suppressed.
2. Lower case “l” and “b” for avoirdupois weight units or “k” and “g” for metric
weight units.
3. The first weight character will be a space, HEX 20, for positive weight or a minus
(-), HEX 2D, if the weight is negative.
4. Decimals are transmitted as a character.
5. Characters separated with a “/” denote one of the characters will be transmitted.
6. Gross weight is denoted by GR. Tare is denoted by TA. Net is denoted by NT.
