Display front panel key functions – Fairbanks FB1100 Series Yellow Jacket FS Package (30047, 30048) User Manual
Page 29
08/13
29
51219 -- Rev. 6
Section 5: Operation
5.1. Display Front Panel Key Functions
LCD Display
Indicates the Net weight after tare operation.
Indicates the weight is stable.
Indicates the weight is at center of zero.
Indicates that the upper limit of the weight is reached.
Indicates that the weight is within the upper and the lower limit.
Indicates that the lower limit of the weight is reached.
Battery is being recharged.
Battery is approximately 50% recharged.
Battery is fully recharged.
