Section 6: Service and Maintenance
6.1. Battery Life
Battery
Load
Battery Life
(Backlight On)
Recharge Time
24921 (NP6V4.5Ah) ABS
4 – 350 Ω load cells
59 hours
8 hours
27391 (NP6V3Ah) SS
4 – 350 Ω load cells
36 hours
8 hours
6.2. Error Codes
Error Code on LCD Display
Description
Error in calibration procedure.
Weighing function disabled. Scale is unstable or error
in application.
Overload or Underload condition
Low battery.
Instrument is in the sleep mode.
“
“
Zero key pressed and instrument is unstable and
unable to weigh.
6.3. Voltages
Description
Measurement Location
Reading
Excitation Voltage
CN6 +E to -E
5 Vdc
Battery Voltage
CN2 1(BL) to 3(R)
~ 6.45 Vdc
Transformer P/S (SS)
CN1 1 to 3
~ 9.55 VAC
