Page 20
Section 3: Programming
08/13
20
51219 -- Rev. 6
3.4.
– RS-232 Settings, continued
2.
- Parity Settings
Display
Descriptions
Set to 7 data bits, even parity, and 1 stop bit
Set to 7 data bits, odd parity, and 1 stop bit
Set to 7 data bits, no parity, and 2 stop bits
8
8
8
8
Set to 8 data bits, no parity, and 1 stop bit
8
8
8
8
Set to 8 data bits, even parity, and 1 stop bit
8
8
8
8
Set to 8 data bits, odd parity, and 1 stop bit
Set to 7 data bits, odd parity, and 2 stop bit
3.5. Exit Settings Menus
When programming is complete and changes have been saved, exit the
program by pressing
. Press
to return to weighing
.
3.6.
– Scale Settings
With the power removed from the instrument, remove the jumper, JP3,
inside the instrument. This will permit access to the configuration menu.
Software Versions 1.6 and higher
Press and hold any one of the following keys
,
,
, or
while turning the scale ON. The display will indicate
,
continue to
hold keys until
is shown on the LCD display. Press
key to
scroll to the
menu.
