Model 9110TH NOx Analyzer Overview of Operating Modes
Teledyne Analytical Instruments 93
4.3.1. PASSWORD SECURITY
SETUP Mode can be protected by password security through the SETUP>PASS menu (Section 5.5) to
prevent unauthorized or inadvertent configuration adjustments.
4.3.2. PRIMARY SETUP MENU
The areas accessed and configured under the primary SETUP Mode menu are shown in Table 4-4.
Table 4-4: Primary Setup Mode Features and Functions
MODE OR FEATURE
CONTROL
BUTTON
LABEL
DESCRIPTION
MANUAL
SECTION
Analyzer Configuration CFG Lists button hardware and software configuration information. 5.1
Auto Cal Feature ACAL
Used to set up and operate the AutoCal feature.
 Only appears if the analyzer has one of the calibration valve
options installed.
5.2, 9.5
Internal Data Acquisition
(DAS)
DAS Used to set up the DAS system and view recorded data. 7
Analog Output Reporting
Range Configuration
RNGE
Used to configure the output signals generated by the
instruments analog outputs.
5.4
Calibration Password Security PASS Turns the calibration password feature ON/OFF. 5.5
Internal Clock Configuration CLK Used to set or adjust the instrument’s internal clock. 5.6
Secondary SETUP Mode
(Advanced SETUP features)
MORE This button accesses the instruments secondary setup menu.
See
Table 4-5
4.3.3. SECONDARY SETUP MENU (SETUP MORE)
The areas accessed and configured under the secondary SETUP Mode menu are shown in Table 4-5.
Table 4-5: Secondary Setup Mode Features and Functions
MODE OR FEATURE
CONTROL
BUTTON
LABEL
DESCRIPTION
MANUAL
SECTION
External Communication
Channel Configuration
COMM
Used to set up and operate the analyzer’s various external I/O
channels including RS-232; RS-485, modem communication
and/or Ethernet access.
8
System Status Variables VARS
Used to view various variables related to the instruments
current operational status.
 Changes made to any variable are not acknowledged and
recorded in the instrument’s memory until the ENTR button
is pressed.
 Pressing the EXIT button ignores the new setting.
 If the EXIT button is pressed before the ENTR button, the
analyzer will beep alerting the user that the newly entered
value has been lost.
5.8
System Diagnostic Features
and
Analog Output Configuration
DIAG
Used to access a variety of functions that are used to configure,
test or diagnose problems with a variety of the analyzer’s basic
systems.
Most notably, the menus used to configure the output signals
generated by the instruments’ analog outputs are located here.
5.9, 5.9.2
