Model 9110TH NOx Analyzer Setup Menu
Teledyne Analytical Instruments 113
To access and navigate the VARS menu, use the following button sequence:
SETUP X.X 7) CONC_PRECISION=AUTO
PREV NEXT JUMP EDIT PRNT EXIT
SETUP X.X CONC_PRECISION=AUTO
AUTO 1 2 3 4 ENTR EXIT
Use these buttons to select
the precision of the
concentration display.
SETUP X.X 8) CLOCK_ADJUST=0 Sec/Day
PREV JUMP EDIT ENTR EXIT
SETUP X.X CLOCK_ADJUST=0 Sec/Day
+ 0 0 ENTR EXIT
Enter sign and number of
seconds per day the clock
gains (-) or loses(+). SETUP X.X 9) CAL_ON_NO2=OFF
PREV NEXT JUMP EDIT PRNT EXIT
SETUP X.X CAL_ON_NO2=OFF
OFF ENTR EXIT
Toggle this button to turn
ON/OFF the analyzer’s
ability to be calibrated
using NO2 span gas.
SETUP X.X DYN_SPAN=OFF
OFF ENTR EXIT
SETUP X.X TPC_ENABLE=OFF
OFF ENTR EXIT
Toggle this button to turn
the Temperature /
Pressure compensation
feature
ON/OFF.
SETUP X.X DYN_ZERO=OFF
OFF ENTR EXIT
Toggle this button to turn
the Dynamic Zero
calibration feature ON/
OFF.
Concentration field
displays all gases.
SAMPLE RANGE=500.0 PPB NOX= XXXX
TST> CAL SETUP
SETUP X.X 0) DAS_HOLD_OFF=15.0 Minutes
PREV NEXT JUMP EDIT PRNT EXIT
SETUP X.X PRIMARY SETUP MENU
CFG DAS RNGE PASS CLK MORE EXIT
SETUP X.X SECONDARY SETUP MENU
COMM VARS DIAG EXIT
SETUP X.X ENTER PASSWORD:818
8 1 8 ENTR EXIT
Toggle these
buttons to enter
the correct
PASSWORD.
In all cases:
EXIT discards the new
setting.
ENTR accepts the
new setting.
SETUP X.X 4) DYN_ZERO=OFF
PREV NEXT JUMP EDIT PRNT EXIT
SETUP X.X 5 ) DYN_SPAN=OFF
PREV NEXT JUMP EDIT PRNT EXIT
DO NOT CHANGE
these settings unless
specifically instructed to by
Teledyne API’s Customer
Service
personnel.
SETUP X.X 6) IZS_SET=50.0 DegC
PREV NEXT JUMP EDIT PRNT EXIT
SETUP X.X DAS_HOLD_OFF=15.0 Minutes
1 5 .0 ENTR EXIT
Toggle these buttons to set
the DAS HOLDOFF time
period in minutes
(MAX = 20 minutes). SETUP X.X 1) MEASURE_MODE=NOXNO
PREV NEXT JUMP EDIT PRNT EXIT
SETUP X.X MEASURE_MODE=NOX-NO
PREV NEXT ENTR EXIT
Toggle these keys to
choose the gas(es) for
analyzer’s measurement
mode.
SETUP X.X 2) STABIL_GAS=NOX
PREV NEXT JUMP EDIT PRNT EXIT
SETUP X.X STABIL_GAS=NOX
NO NO2 NOX O2 ENTR EXIT Use these buttons to select
which gas will be reported
by the STABIL test
function.
(O 2 is only available if the
optional O 2 sensor is
installed)
SETUP X.X 3) TPC_ENABLE
PREV NEXT JUMP EDIT PRNT EXIT
Toggle this button to turn
the Dynamic Span
calibration feature ON/
OFF.
