Model 9110T NOx Analyzer
Data Acquisition System (DAS) and APICOM
Teledyne Analytical Instruments
168
7.1.1.2. DAS Configuration Limits
The number of DAS objects are limited by the instrument’s finite storage capacity. For information
regarding the maximum number of channels, parameters, and records and how to calculate the file size
for each data channel, refer to the DAS manual downloadable from the Teledyne website at
http://www.teledyne-api.com/manuals/ under Special Manuals.
7.1.2. VIEWING DAS DATA AND SETTINGS
DAS data and settings can be viewed on the front panel through the following menu sequence.
Continue pressing NEXT to view remaining
DAS channels
SAMPLE
RANGE=500.0 PPB NOX= XXXX
TST> CAL
SETUP
PRM>
PREV
PV10
NEXT
NX10
Button
Selects the previous parameter on the list
Selects the next parameter on the list
Moves the VIEW backward 1 records or channel
Moves the VIEW backward 10 record
Moves the VIEW forward 1 record or channel
Moves the VIEW forward 10 records
FUNCTION
Buttons only appear when applicable.
DAS VIEW – Touchscreen Functions
SETUP X.X
PRIMARY SETUP MENU
CFG
DAS
RNGE PASS CLK MORE
EXIT
SETUP X.X
DATA ACQUISITION
VIEW
EDIT
EXIT
SETUP X.X
CONC: DATA AVAILABLE
NEXT VIEW
EXIT
SETUP X.X
101:21:00 NXCNC1=59.0346 PPB
PV10 PREV NX10
NEXT
PRM> EXIT SETUP X.X 101:22:00 NXCNC1=000.0000 PPB PV10 PREV NX10 NEXT EXIT SETUP X.X 101:21:00 NOCNC1=22.0934 PPB PV10 PREV NX10 NEXT EXIT SETUP X.X CALDAT: DATA AVAILABLE NEXT VIEW EXIT SETUP X.X 101:19:45 NXZSC1=401.0346 PV10 PREV NX10 NEXT PRM> EXIT SETUP X.X 102:04:55 NXZSC1=400.9868 PV10 PREV NX10 NEXT EXIT SETUP X.X 101:19:45 NXSLP1=0.9987 PPB PV10 PREV NX10 NEXT EXIT SAMPLE RANGE=500.0 PPB NOX= XXXX TST> CAL SETUP Concentration field displays all gases.
