Model 9110T NOx Analyzer Setup Menu
Teledyne Analytical Instruments 116
5.9.1. SIGNAL I/O
The signal I/O diagnostic mode allows a user to review and change the digital and analog input/output
functions of the analyzer. Refer to Appendix A for a complete list of the parameters available for review
under this menu.
I MPORTANT I MPACT ON R EADINGS OR D ATA
Any changes of signal I/O settings will remain in effect only until the
signal I/O menu is exited. Exceptions are the ozone generator override
and the flow sensor calibration, which remain as entered when exiting.
Access the signal I/O test mode from the DIAG Menu (Figure 5-4), then press:
EXAMPLE
DIAG SIGNAL I / O
PREV NEXT JUMP ENTR EXIT
DIAG I / O 0) EXT_ZERO_CAL=OFF
PREV NEXT JUMP PRNT EXIT
Press JUMP to go
directly to a specific
signal
See Appendix A-4 for
a complete list of
available SIGNALS
DIAG I / O JUMP TO: 12
1 2 ENTR EXIT
EXAMPLE:
Enter 12 to Jump to
12) ST_SYSTEM_OK=ON
DIAG I / O 12) ST_SYSTEM_OK = ON
PREV NEXT JUMP ON PRNT EXIT
Exit to return
to the
DIAG menu
Press NEXT & PREV to
move between signal
types.
Pressing the PRNT button will send a formatted
printout to the serial port and can be captured
with a computer or other output device.
Toggle ON/(OFF) button to
change status.
