© 2006 Alamo Industrial Section 8 - 1
Axtreme Boom (Asy Man) 07/06
Axtreme Boom
Section 8
Remote Valve Cable
Installation
This Control valve is the Standard 5 Spool that is remote cable controlled, with the 5 Th.
Spool operating the Door or the Swivel Head Mount Option through a diverter valve. The
Standard Pump System is used to supply the cylinder valve control circuit.
NOTE: This shows a basic mount for the frame installation and may not be the
same for your tractor model. The way the frame mounts to the tractor compo-
nents can vary with tractor model. See the installation drawings shipped with the
unit for the specific tractor type mount and hardware components. IN SOME
CASES THE MANUAL INSTRUCTION MAY VARY FROM THE INSTALLA-
TION DRAWING INSTRUCTION, THE INSTALLATION DRAWING INSTRUC-
TIONS WILL OVERRIDE THE ASSEMBLY MANUAL INSTRUCTIONS WHICH
ARE BASIC. THE INSTALLATION DRAWINGS ARE FOR A SPECIIFIED
TRACTOR.
