Axtreme boom, Wheel weight installation – Alamo Axtreme 02984405 User Manual
Page 45
© 2006 Alamo Group Inc.
Section 5 - 1
Axtreme Boom (Asy. Man.) 07/06
Axtreme Boom
Wheel Weight
Installation
Section 5
This section show the secondary weight that can be
added to the LH rear wheel.
NOTE: This shows a basic mount for the frame installation and may not be the
same for your tractor model. The way the frame mounts to the tractor components
can vary with tractor model. See the installation drawings shipped with the unit for
the specific tractor type mount and hardware components. IN SOME CASES THE
MANUAL INSTRUCTION MAY VARY FROM THE INSTALLATION DRAWING
INSTRUCTION, THE INSTALLATION DRAWING INSTRUCTIONS WILL OVER-
RIDE THE ASSEMBLY MANUAL INSTRUCTIONS WHICH ARE BASIC. THE
INSTALLATION DRAWINGS ARE FOR A SPECIIFIED TRACTOR.
