M o d e l N o . M E - 6 9 9 2 B C a b l e S t a y e d B r i d g e C o n s t r u c t i o n S u g g e s t i o n s
Cable Stayed Bridge Construction Suggestions
Thread a cord that
is knotted at one
end through a hole
in the I-Beam.
Cord
Tensioning
Clip
Full
Round
PAStrack
section
Flat
Connector
Nut and Bolt
for PAStrack
Cord
Tensioning
Clip
Begin and
end the
cord here.
Loop the cord
through the Cord
Tensioning Clip.
#2
#1
Full
Round
Add a second PAStrack
section to each side.
Cord
Tensioning
Clip
Tie a knot at
one end of
the cord.
Cord
Tensioning
Clip
Double
Cords
